| Rated input line voltage | 380V (-20% ~ +20%) |
| Grid frequency | 50Hz |
| Efficiency | ≥97% |
| Grid configuration | 3P3W/3P4W |
| Max. parallel units | Unlimited |
| Single CT source-side sampling (parallel mode) | Supported |
| High protection capability | Supported |
| Harmonic compensation | Supported |
| Reactive power compensation | Supported |
| Unbalance compensation | Supported |
| Harmonic filtering range | 2nd-13th (any orders selectable) |
| Harmonic filtering rate | >95% |
| Target power factor | Adjustable from -1 to +1 |
| Communication interface | RS485, Modbus protocol |
| Monitoring | Supports centralized monitoring |
| Altitude | s1500m; for 1500-4000m, derate 1% per 100m per GB/T 3859.2 |
| Operating temperature | -10°C~+40°C |
| Protection rating | IP44 (other IP ratings available on request) |
