Name: CJ19 Series Capacitor Switching Contactor
Brand: YIDEK
SKU: 00014
Rating: 4.9 (57 reviews)

CJ19 Series Capacitor Switching Contactor

Capacitor switching devices are designed for fast and reliable switching of capacitor banks, ensuring stable reactive power compensation under various operating conditions.

Get in touch→

Order specifications

Principle: It is a traditional mechanical switch, but with the addition of auxiliary contacts—equipped with resistors to suppress inrush current—alongside the main contacts.

Characteristics: Mature technology, low cost, and a simple circuit. However, switching operations generate mechanical noise; furthermore, due to the physical characteristics of mechanical contacts, true "zero-crossing switching" cannot be achieved, and the resulting inrush current impacts the lifespan of the capacitors.

Technical Parameter

Specifications		CJ19-25	CJ19-32	CJ19-43	CJ19-63	CJ19-95	CJ19-115	CJ19-150	CJ19-170
Controllable capacitor capacity Qe kvar	230V	6	9	10	15	22	34.5	46	52
	400V	12	18	20	30	40	60	80	90
Rated isolation voltage UiV		690
Rated operating voltage Ue V		380					400
Agreed free air heating current Ith A		25	32	43	63	95	200
Rated working current leA		17	26	29	46	63	87	115	130
Ability to restrain inrush current		≤20Ie
Control power supply voltage UsV		48, 110, 127, 230, 400
Auxiliary Contact	Agreed heating current Ith A	10
	Rated operating voltage Ue V	AC380V DC220V
	Rated control capacity	360VA (AC-15) or 33W (DC-13)
Operating frequency times/hour		120
Electrical life is 104 times		10					2
Mechanical life 104 times		100
Weight Kg		0.42	0.49	0.50	1.35	1.5	2.5
